Power Customization: The default power is stepless adjustable; fixed power or wider power adjustment range can be customized according to customer requirements.
Voltage Customization: Standard 220V/50Hz; 110V/60Hz and other overseas voltage standards can be customized for Europe, America and Southeast Asia markets.
Tank Size Customization: Non-standard inner tank length, width and height can be customized according to workpiece size; special capacity is supported.
Function Customization: Optional upgraded timing, precise constant temperature control, degassing function and memory start-stop function to meet high-standard laboratory and dental medical requirements.
Logo & Panel Customization: Custom body LOGO, brand silk printing, multi-language control panel.
Drainage Customization: Models below 6L have no drainage by default; drain ball valve can be installed additionally for 3L/4.5L by customization.
| Product Model | Capacity | Ultrasonic Power | Ultrasonic Frequency | Timer Range | Heating Temperature | Heating Power | Tank Size(L×W×H)mm | Machine Overall Size(L×W×H)mm | Drainage | Single Package Size(L×W×H)mm | Master Carton Size & Q'ty | Single Net Weight | Carton Gross Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| HT-20AL | 3L | 50~120W | 40KHz | 1~30min | Room Temp~80℃ | 200W | 240×135×100 | 270×170×190 | No | 350×260×310 | 790×380×690 (6pcs) | 4.0KG | 25.0KG |
| HT-25AL | 4.5L | 50~120W | 40KHz | 1~30min | Room Temp~80℃ | 200W | 300×150×100 | 330×180×190 | No | 430×280×380 | 860×460×820 (6pcs) | 4.2KG | 32.0KG |
| HT-30AL | 6L | 70~180W | 40KHz | 1~30min | Room Temp~80℃ | 400W | 300×150×150 | 330×180×270 | Yes | 430×280×380 | 860×460×820 (6pcs) | 6.0KG | 38.0KG |
| HT-40AL | 10L | 100~240W | 40KHz | 1~30min | Room Temp~80℃ | 400W | 300×240×150 | 330×270×270 | Yes | 430×370×380 | 760×460×780 (4pcs) | 8.0KG | 34.0KG |
| HT-50AL | 14L | 120~300W | 40KHz | 1~30min | Room Temp~80℃ | 400W | 300×240×200 | 330×270×320 | Yes | 430×370×430 | 760×460×880 (4pcs) | 9.0KG | 42.0KG |
| HT-60AL | 15L | 150~360W | 40KHz | 1~30min | Room Temp~80℃ | 600W | 330×300×150 | 360×330×270 | Yes | 460×430×390 | 880×490×790 (4pcs) | 10.0KG | 42.0KG |
| HT-70AL | 19L | 170~420W | 40KHz | 1~30min | Room Temp~80℃ | 600W | 330×300×200 | 360×330×320 | Yes | 460×430×430 | 880×490×890 (4pcs) | 11.0KG | 48.0KG |
| HT-80AL | 22L | 200~480W | 40KHz | 1~30min | Room Temp~80℃ | 800W | 500×300×150 | 550×330×270 | Yes | 630×430×390 | 670×460×790 (2pcs) | 13.0KG | 28.0KG |
| HT-100AL | 30L | 240~600W | 40KHz | 1~30min | Room Temp~80℃ | 1000W | 500×300×200 | 550×330×320 | Yes | 630×430×430 | 670×460×890 (2pcs) | 15.0KG | 32.0KG |
Ultrasonic Power: Stepless adjustable with multiple levels to adjust cleaning strength freely.
Time Setting: 1–30 minutes digital adjustable, automatic stop after timing.
Temperature Setting: Digital control from room temperature to 80℃, constant temperature heating accelerates oil dissolution.
Product Material: Inner tank and outer shell adopt high-quality stainless steel, rust and corrosion resistant.
Tank Craft: Integral stamping forming without welding seams, no water leakage and no dirt hiding.
Component Quality: Adopts imported high-quality ultrasonic accessories with stable vibration and long service life.
Drainage System: Models 6L and above equipped with drain ball valve for easy water replacement.
Quality Certification: Fully certified by CE, ROHS, FCC, suitable for global export.




Standard Stock Models: 3L~30L standard models in stock, ship within 1–3 working days after payment.
Custom Orders: Voltage, size, LOGO and function customization, production cycle 5–7 working days.
Bulk Orders: Over 10 pieces bulk order can arrange priority production, fastest delivery within 3 working days.
Shipping Method: Express for small units, logistics for large volume; support global shipping, air freight and sea freight for overseas orders.
Warranty: 1-year full machine warranty; free repair and replacement for core ultrasonic components under non-human damage.
Technical Support: Provide operation tutorials, cleaning solution ratio and remote fault guidance 24/7.
Return & Replacement: Free replacement or parts supply for damaged or quality problems on arrival, no extra cost for customers.
Spare Parts Supply: Original spare parts such as transducer, control panel and inner tank are supplied permanently for later maintenance.
Custom Follow-up: One-to-one service for custom orders, confirm parameters and LOGO design to ensure compliance with requirements.
