Ht Washer Equipment Focus on washing machine equipment solutions.
 |
| Quantity: | |
|---|---|
| Parameter Items | 3L Standard Model | 5L Standard Model | Customizable Options |
|---|---|---|---|
| Product Name | Small Desktop Ultrasonic Cleaning Machine (Mechanical Control, No Heating) | Small Desktop Ultrasonic Cleaning Machine (Mechanical Control, No Heating) | Custom model (adjusted according to needs) |
| Control Mode | Mechanical knob control | Mechanical knob control | Mechanical control (fixed, no touch screen option) |
| Heating Function | No heating | No heating | No heating (fixed, not customizable) |
| Timer Range | 1-30 minutes (adjustable) | 1-30 minutes (adjustable) | 1-60 minutes (customizable) |
| Tank Capacity | 3L | 5L | 6L/10L/15L |
| Inner Tank Material | 304 stainless steel | 304 stainless steel | 316 stainless steel |
| Inner Tank Size (mm) | 180×140×120 | 220×160×140 | Customized according to capacity |
| Ultrasonic Power | 60W | 100W | 120W/150W (adjusted with capacity) |
| Ultrasonic Frequency | 40kHz | 40kHz | 40kHz (fixed, suitable for small parts cleaning) |
| Ultrasonic Components | Imported high-quality accessories | Imported high-quality accessories | High-grade imported components (customizable) |
| Drainage System | No | No | Drainage ball valve (6L+) |
| Cooling System | No | No | High-efficiency cooling fan (10L+) |
| Power Supply | AC220V/50Hz | AC220V/50Hz | 110V/60Hz (overseas customization) |
| Working Noise | ≤60dB | ≤60dB | ≤55dB (low-noise customization) |
| Body Material | 304 stainless steel (inner + outer) | 304 stainless steel (inner + outer) | 316 stainless steel (inner + outer, customizable) |
| Applicable Objects | Eyeglasses, jewelry, small clock parts, small hardware | Eyeglasses, jewelry, small hardware, laboratory small parts | Adjusted according to tank capacity |
| Quality Certification | CE, ROHS, FCC | CE, ROHS, FCC | CE, ROHS, FCC (full set) |
Compact Desktop Design
Small size, lightweight, suitable for desktop placement, no need for extra space, perfect for homes, shops, studios and laboratories, easy to move and store.
Simple Mechanical Control
Mechanical knob operation, intuitive and easy to use, timer adjustable from 1 to 30 minutes, no complicated settings, even the elderly and novices can get started quickly, reducing operation difficulty.
No Heating & Energy Saving
No heating function, focusing on normal-temperature cleaning, energy-saving and power-saving, low failure rate, suitable for daily cleaning needs that do not require high temperature, and longer service life.
High-quality Material
Both inner and outer shells are made of 304 stainless steel, corrosion-resistant, rust-proof, easy to clean, and the cleaning tank is formed by stamping without welding seams, firm and durable, not easy to leak.
Efficient Cleaning Without Dead Corners
Adopt 40kHz ultrasonic frequency and imported high-quality ultrasonic components, strong output power, ultrasonic cavitation effect can deeply penetrate gaps and blind holes, thoroughly remove all kinds of dirt, no damage to workpieces.
Multi-scenario Application
Widely used for cleaning small hardware parts, mechanical accessories, jewelry, eyeglass frames, laboratory small parts, clock parts, etc., meeting the small-scale cleaning needs of multiple scenarios.
Reliable Quality & Certification
Fully certified by CE, ROHS, FCC, in line with international quality standards, ultrasonic components are made of imported high-quality accessories, stable performance and low failure rate.
Cost-effective & Practica
Affordable price, complete functions, suitable for small-scale cleaning needs, no need to purchase expensive large-scale equipment, saving purchase costs for homes, shops and studios.
Save Time & Labor
Replace traditional manual cleaning, efficient dead-angle-free cleaning, 3-5 times more efficient than manual cleaning, saving a lot of time and labor costs, especially suitable for shops and studios with frequent cleaning needs.
Protect Cleaned Items
Gentle physical cleaning, no scratches, corrosion or damage to the surface of items, effectively protecting the integrity of jewelry, eyeglasses, precision small parts and other items, reducing the loss caused by improper cleaning.
Easy to Maintain & Durable
Simple structure, easy daily maintenance, only need to regularly clean the inner tank; high-quality stainless steel material and imported components ensure long service life, reducing later maintenance and replacement costs.
Energy Saving & Environmental Protection
No heating function, low power consumption, energy saving and environmental protection; suitable for water-based cleaning agents, non-toxic and pollution-free, ensuring the safety of the use environment and the health of users.
Flexible Customization
Support customization of tank capacity, inner tank material, timer range and other parameters, which can be tailored according to actual use needs, strong adaptability, meeting the diverse needs of different customers.
✅ Product Parameters
Time setting
The mechanical timer can be adjusted from 1 to 30 minutes
Product material
Both the inner and outer shells are made of high-quality stainless steel
Product advantages
The cleaning tank is formed by stamping without welding seams
Component quality
Ultrasonic components are made of imported high-quality accessories
Drainage system
6L and above models are equipped with drainage ball valves
Cooling system
high-efficiency cooling fans are installed for 10L and above
Quality certificate
fully certified by CE, ROHS, FCC
| Product Model | Capacity | Ultrasonic Power | Ultrasonic Frequency | Timer Range | Heating Temperature | Heating Power | Cleaning Tank Size | Machine Overall Dimensions | Drainage | Single Unit Package Size | Master Carton Size | Single Unit Gross Weight | Total Carton Gross Weight | ||||
| L | W | KHZ | min | ℃ | W | (LⅹwⅹH)mm | (LⅹwⅹH)mm | (LⅹwⅹH)mm | (LⅹwⅹH)mm | KG | KG | ||||||
| HT-06T | 0.6 | 60 | 40 | 1～30 | no | / | 150x85x65 | 180x110x140 | no | 230×200×220 | 480×420×480（8pcs) | 1.5 | 16.0 | ||||
| HT-08T | 1.3 | 60 | 40 | 1～30 | no | / | 150×135×65 | 180×170×140 | no | 260×260×260 | 540×540×600（8pcs) | 2.5 | 20.0 | ||||
| HT-10T | 2 | 80 | 40 | 1～30 | no | / | 150x135x100 | 180x170x180 | no | 240×220×240 | 490×470×520（8pcs) | 2.3 | 20.0 | ||||
| HT-20T | 3 | 120 | 40 | 1～30 | no | / | 240x135x100 | 270x170x190 | no | 350x260x310 | 790×380×690（6pcs) | 4.0 | 25.0 | ||||
| HT-25T | 4.5 | 120 | 40 | 1～30 | no | / | 300x150x100 | 330x180x190 | no | 430x280x380 | 860×460×820(6pcs) | 4.2 | 32.0 | ||||
| HT-30T | 6 | 180 | 40 | 1～30 | no | / | 300x150x150 | 330x180x270 | yes | 430x280x380 | 860×460×820(6pcs) | 6.0 | 38.0 | ||||
| HT-40T | 10 | 240 | 40 | 1～30 | no | / | 300x240x150 | 330x270x270 | yes | 430x370x380 | 760×460×780(4pcs) | 8.0 | 34.0 | ||||
| HT-50T | 14 | 300 | 40 | 1～30 | no | / | 300×240×200 | 330×270×320 | yes | 430×370×430 | 760×460×880(4pcs) | 9.0 | 42.0 | ||||
| HT-60T | 15 | 360 | 40 | 1～30 | no | / | 330×300×150 | 360×330×270 | yes | 460×430×390 | 880×490×790(4pcs) | 10.0 | 42.0 | ||||
| HT-70T | 19 | 420 | 40 | 1～30 | no | / | 330×300×200 | 360×330×320 | yes | 460×430×430 | 880×490×890(4pcs) | 11.0 | 48.0 | ||||
| HT-80T | 22 | 480 | 40 | 1～30 | no | / | 500×300×150 | 550×330×270 | yes | 630×430×390 | 670×460×790(2pcs) | 13.0 | 28.0 | ||||
| HT-100T | 30 | 600 | 40 | 1～30 | no | / | 500×300×200 | 550×330×320 | yes | 630×430×430 | 670×460×890(2pcs) | 15.0 | 32.0 | ||||
